3.6 Stretcher Mode
The following steps outline the procedure to convert the FROG-XT6 into stretcher mode.
3.6.1 Converting to Stretcher Mode
i. Fold down the three seat backs behind buoyancy
panel A.
ii. Use one 13mm spanner/socket remove the two
fittings on each seat as indicated below and fold
down each seat (Note: pinch hazards). There is
one fitting on each side of the seat to remove.
iii. These bolts are then replaced in the cross holes on both sides as indicated below.
