Rev 0.2 13 | P a g e
3.6.2 Stretcher Positioning
The clamp channel has been designed to fit the Ferno Basket stretcher. However the clamp
channel can be adjusted in height to accommodate the use of alternative stretcher types.
Please note that not all stretcher types will fit.
The clamp should be checked and adjusted to fit the specific stretcher type in use prior to
operation.
i. Three people should handle the stretcher. Two at the head end/one at the foot end.
ii. Line up the stretcher as indicated below in figure 1.
iii. Guide the head of the stretcher onto the folded seats.
iv. As the stretcher is slid onto the seat the rim of the stretcher should be lined up with
the clamp channel.
v. When in position the head end of the stretcher should have a small (25mm) clearance
with the doorframe.
Figure 2 Stretcher Fitting (Buoyancy panels have been removed for illustration purposes only.)
