3.6.3 Securing the Stretcher
1. Loosen the clamp thumbscrew,
then pass the clamp through hand
hold in the stretcher
2. Turn clamp 90 degrees with
folded edge upward
3. Tighten clamp with thumb screw –
this should be tight enough to
prevent the stretcher from sliding
longitudinally
4. Use the supplied stretcher straps
to secure the stretcher using the two
attachment points
