— English Fillcontrol Auto Make-up and degassing — 06.07.2016 - Rev. B
10.3 System degassing inspection
Inspect the "SE" system degassing unit (only with Fillcontrol Auto 2PS).
Proceed as follows:
1. Press "Manual" at the controller to switch to manual mode.
• The Auto LED at the operator panel flashes to visually indicate that manual mode is active.
• In manual mode, you manually activate and deactivate the "SE" system degassing unit.
2. Run 10 cycles in "SE" mode.
• The gas must be eliminated before the next cycle starts.
3. Subsequently, check the following conditions:
• With cold water, the vacuum gauge must eventually show a value of approx. -1 bar.
• The "Insufficient water" message must not be displayed at the controller.
4. After the inspection is completed, reset the device to Automatic mode.
•
"Next" and "Back" buttons
– Select "SE" system degassing
•
"OK" button
– Starts system degassing
•
"Auto" button
– Return to Automatic mode
2.5 bar
SE▲*
010 h
* Flashing "SE
▲
“ mode is
active
10.4 Inspection of pressure-carrying components
Comply with all applicable national regulations for the operation of pressure equipment. De-pressurise all pressurised components prior
to inspection (see disassembly information).
