Reflex Servitec S - Commissioning

Commissioning
20
— English Vacuum spray degassing — 28.08.2019 - Rev. B
Item
numbers
Terminal
number
Signal
Function
Wiring
11
26 C
Potential-free group alarm contact (max. 230 V / 8 A) User, optional
27
NC
28 NO
12
29 N
"PU" pump for degassing. Factory 30 M1
31 PE
13 32 PE Earthing Factory
14
33 PE
230 V power supply via mains cable and plug. Factory 34 N
35 L
6.6 Installation and commissioning certificate
Data shown on the type plate: P
0
Type: P
SV
Manufacturing number:
This device has been installed and commissioned in accordance with the instructions provided in the operating manual. The
settings in the controller match the local conditions.

Note!
When any factory
-set values of the device are changed, you must enter this information in the Maintenance
certificate, see chapter 10.3 "Maintenance certificate" on page 29 .
For the installation
Place, date Company Signature
For the commissioning
Place, date Company Signature
7 Commissioning

Note!
Confirm that
installation and start-up have been carried out correctly using the installation, start-up and
maintenance certificate. This action is a prerequisite for the making of warranty claims.
– Have the Reflex Customer Service carry out commissioning and the annual maintenance.

Note!
The app guides you through commissioning see chapter
9.1 "Reflex Control Smart" on page 23
