Reflex variomat 1 User Manual

reflex ’variomat’
General description
30
Dimensions, weights
’variomat 1’, ’variomat 2-1’ Control unit with 1 pump
Type Item no. p
0
H W D Connection Weight
bar mm mm mm p O WM VG kg
variomat 1 6910100
≤ 2.5 680 530 580 Rp 1 Rp 1 Rp ½ 2 x G 1 25
variomat 2-1/60 6910200
≤ 4.8
680 530 670 Rp 1 Rp 1 Rp ½ 2 x G 1 28
variomat 2-1/75 6910500
≤ 6.5
770 530 630 Rp 1 Rp 1 Rp ½ 2 x G 1 35
variomat 2-1/95 6910600
≤ 8.0
770 530 540 Rp 1 Rp 1 Rp ½ 2 x G 1 37
’variomat 2-2’ Control unit with 2 pumps
Type Item no. p
0
H W D Connection Weight
bar mm mm mm p O WM VG kg
variomat 2-2/35
6911100 ≤ 2.5 680 700 780 G 1¼ G 1¼ Rp ½ 2 x G 1¼ 54
variomat 2-2/60 6911200
≤ 4.8
680 700 780 G 1¼ G 1¼ Rp ½ 2 x G 1¼ 58
variomat 2-2/75 6911500
≤ 6.5
760 700 730 G 1¼ G 1¼ Rp ½ 2 x G 1¼ 72
variomat 2-2/95 6911600
≤ 8.0
760
700 730 G 1¼ G 1¼ Rp ½ 2 x G 1¼ 76
Vn nominal volume / litre
VG basic
vessel
VG secondary
vessel
VW thermal
insulation
(optional) for heating systems
(optional)
Type ∅ D H h A Weight Item no. Item no. Item no.
mm mm mm kg
200
634 1060 146
G 1 37 6600000 6610000 7985700
300
634 1360 146
G 1 54 6600100 6610100 7986000
400
740 1345 133
G 1 65 6600200 6610200 7995600
500
740 1560 133
G 1 78 6600300 6610300 7983900
600
740 1810 133
G 1 94 6600400 6610400 7995700
800
740 2275 133
G 1 149 6600500 6610500 7993800
1000
740 2685 133
G 1 156 6600600 6610600 7993900
1000
1000 2130 350
G 1 320 6600705 6610705 7986800
1500
1200 2130 350
G 1 465 6600905 6610905 7987000
2000
1200 2590 350
G 1 565 6601005 6611005 7987100
3000
1500 2590 380
G 1 795 6601205 6611205 7993200
4000
1500 3160 380
G 1 1080 6601305 6611305 7993300
5000
1500 3695 380
G 1 1115 6601405 6611405 7993400
