Rega Elicit-R User Manual

FRONT PANEL
Powering Up- Depressing the power switch to the left of the control panel turns on
the amplifier. The Rega logo will glow red. After several seconds you may hear a
gentle click, indicating that the switch-on relay has been released and the amplifier
is ready for use. Always allow the Elicit- R to fully power down (indicated by the
power switch LED extinguishing after 2-3 seconds) before switching on again, so that
the self-test circuitry can complete its reset cycle.
Input Selection- The inputs are selected by firstly pressing the input selector
switch, to the left of the input LED’s, then turn the volume control knob to the
required input. Pressing the input selector switch again will deactivate the input
selection function. If left for more than five seconds the input selection function will
automatically return to volume control. Alternatively this can be done via the
remote handset.
Mute- The mute function mutes both the pre-amplifier and power amplifier speaker
outputs.
9

Rega Elicit-R Specifications

General

Amplifier class	-
Frequency range	10 - 85000 Hz
Input sensitivity	196 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	31.6 dB
Total Harmonic Distortion (THD)	0.003 %
Dynamic power per channel (4 Ohm)	162 W
Dynamic power per channel (6 Ohm)	127 W
Dynamic power per channel (8 Ohm)	105 W
Audio (L/R) in	7
Audio (L/R) out	3
Phono audio in (L,R)	Yes
Speakers connectivity type	Binding post
AC input voltage	115 - 230 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	375 W
Purpose	Home
Product color	Black
Volume control	Rotary
Connectivity technology	Wired

Weight and Dimensions

Depth	340 mm
Width	432 mm
Height	82 mm
Weight	13000 g
