Rega Elicit-R User Manual

12
OPERATING TEMPERATURE & SHORT CIRCUIT PROTECTION
Recommended Ambient operating temperature 5 to 35°C.
Allow adequate air circulation around the heat sinks on the left and right hand sides,
as these are the heat sinks for the power amplifier and will run hot with high
listening levels. This unit is intended for use in moderate climates.
If in the event that the speaker leads are shorted, the fold back short circuit
protection will protect the output stage from excessive currents. This protection
circuit is not placed in the audio signal path and therefore does not affect sound
quality.
Warning: To reduce the risk of fire, electric shock or product damage, do not
expose the unit to rain, moisture, dripping or splashing and ensure that no objects
filled with liquids, such as vases shall be placed upon it. Do not remove the case
covers. There are no user serviceable parts inside.
No naked flame sources, such as lighted candles, should be placed on the apparatus.

Rega Elicit-R Specifications

General

Amplifier class	-
Frequency range	10 - 85000 Hz
Input sensitivity	196 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	31.6 dB
Total Harmonic Distortion (THD)	0.003 %
Dynamic power per channel (4 Ohm)	162 W
Dynamic power per channel (6 Ohm)	127 W
Dynamic power per channel (8 Ohm)	105 W
Audio (L/R) in	7
Audio (L/R) out	3
Phono audio in (L,R)	Yes
Speakers connectivity type	Binding post
AC input voltage	115 - 230 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	375 W
Purpose	Home
Product color	Black
Volume control	Rotary
Connectivity technology	Wired

Weight and Dimensions

Depth	340 mm
Width	432 mm
Height	82 mm
Weight	13000 g
