Rega Elicit-R User Manual

TECHNICAL SPECIFICATION
Power output
105 Watts per channel into 8Ω
127 Watts per channel into 6Ω
162 Watts per channel into 4Ω
Input sensitivity for 105 Watts into 8Ω
Line inputs (input 1 switch set to line) 1-5 and record - 196mV load 10K
Phono (input 1 switch set to phono) - 2mV Load 47K in parallel with 220pF
Direct input - 760mV Load 50K
Power amplifier gain - 31.6dB
Record output - 196mV for rated inputs
Pre-amplifier output - 760mV for rated inputs
Dimensions in mm - W432 x H82 x D340
Weight - 13kg
14

Rega Elicit-R Specifications

General

Amplifier class	-
Frequency range	10 - 85000 Hz
Input sensitivity	196 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	31.6 dB
Total Harmonic Distortion (THD)	0.003 %
Dynamic power per channel (4 Ohm)	162 W
Dynamic power per channel (6 Ohm)	127 W
Dynamic power per channel (8 Ohm)	105 W
Audio (L/R) in	7
Audio (L/R) out	3
Phono audio in (L,R)	Yes
Speakers connectivity type	Binding post
AC input voltage	115 - 230 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	375 W
Purpose	Home
Product color	Black
Volume control	Rotary
Connectivity technology	Wired

Weight and Dimensions

Depth	340 mm
Width	432 mm
Height	82 mm
Weight	13000 g
