Rega Elicit-R User Manual

1
INTRODUCTION
The Elicit- R is built to the highest standard and designed to deliver the best possible
audio performance whilst remaining simple to use and easy to setup.
Our recent development work in amplifier design circuitry has allowed us to further
advance the Elicit- R performance by using new and improved power amplifier
circuits (based around the hugely successful Rega Brio- R amplifier) combined with
FET II discrete line pre-amplifiers and a programmable stepped attenuator volume
control.
The Elicit- R includes a high quality built in moving magnet phono stage which can be
switched off by the user if so required. A simple switch on the rear panel switches to
a secondary input socket at line level. This socket can be used with any line level
product, however, the circuit has dedicated isolation making it ideal for an external
phono stage such as the Rega Aria MM/MC.
These features coupled with Polypropylene capacitors (used throughout the signal
path), improved power supplies, increased output power to 100 Watts per channel all
housed in a brand new custom Rega designed case, combine to give the best
performance Elicit to date.

Rega Elicit-R Specifications

General

Amplifier class	-
Frequency range	10 - 85000 Hz
Input sensitivity	196 mV
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	31.6 dB
Total Harmonic Distortion (THD)	0.003 %
Dynamic power per channel (4 Ohm)	162 W
Dynamic power per channel (6 Ohm)	127 W
Dynamic power per channel (8 Ohm)	105 W
Audio (L/R) in	7
Audio (L/R) out	3
Phono audio in (L,R)	Yes
Speakers connectivity type	Binding post
AC input voltage	115 - 230 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	375 W
Purpose	Home
Product color	Black
Volume control	Rotary
Connectivity technology	Wired

Weight and Dimensions

Depth	340 mm
Width	432 mm
Height	82 mm
Weight	13000 g
