6
REAR PANEL CONNECTIVITY
Record Input and Output- This is a line level input and output intended for use with
a recording device such as a CD/DVD recorder, MD, tape cassette machine or sound
card. Selecting the record function on the amplifier front panel enables the input.
This input is completely independent to inputs 1-5 and can be used to monitor the
record function and quality without affecting the source being recorded. The output
is a record signal and is the same signal as selected by the main input selector 1-5
and is not affected by the volume control.
Record Output Link- This output is in parallel to the Record output, and can be used
to drive ancillary components like headphone amplifiers etc, when a signal
unaffected by the volume control and selected by the main input selector is required.
Direct Input- This input is routed directly to the power amplifier input with no
volume control. The intended use is with multi channel systems, where the traditional
two-channel system is used as the front speakers. This input can also be used with
an external pre-amplifier if so desired. The sensitivity is 760mV for maximum
output.
CAUTION : As this input has no volume control, if a source like a CD player is
connected to this input the speakers will be driven to their maximum. This could
potentially damage the speakers.
