COLOR GAUGE FUNCTION
Black 16 to 4 All Grounds
Black / White 16 Halon Automatic Fire Extinguishing System
Blue 14 Interior Lights
Blue 10 Cabin Light Main Feed
Blue / White 16 Transom Courtesy Lights
Blue / White 14 Cockpit Lights
Brown 12 Water Pressure Pump
Brown 16 Aft Bilge Pump / Manual
Brown 16 Fwd. Bilge Pump / Manual
Brown / Black 10 Overboard Discharge
Brown / Pink 16 Carbon Monoxide Detector
Brown / Red 16 Fwd. Auto Bilge Pump
Brown / White 16 Aft Auto Bilge Pump
Grey 16 Bow Navigation Lights
Grey / Black 16 Mast Light (Anchor Light)
Grey / White 16 Mast Light (Fwd. Running)
Green 16 Tank Level Monitor
Green 8 Bonding
Orange 16 Windshield Wiper / Run
Orange 12 Refrigerator, Hatch Run
Orange 10 Spotlight
Orange / Black 16 Horn
Orange / White 16 Windshield Wiper Park
Purple 16 Hour Meter
Red 16 Gas Vapor Detector, Stereo Remote, Breaker
To Dash Feed Lines
Red 14 Positive Feed, Electronics
Red 8 Positive Feed, Alternator Charge
Red 8 Positive Feed, Alternator Charge
Red 4 Positive Feed
Red 2 Positive Feed, Starter Battery
4-5
Systems
