A dash fuse box protects the individual switch controlled components
and is located in the starboard bow storage locker.
The ignition panel is protected by a 20 amp breaker mounted to the
panel itself. All gauges and helm electrical systems like the head radio
unit are protected by a dashboard protection fuse located underneath
the dash connected to the ignition switch. Your fusion stereo is also
protected by a fusion installed stereo memory fuse located underneath
the dash along the radio wiring, in addition to the Regal provided
stereo memory fuse in the engine compartment near the battery
switch. Additionally, there is an automatic bilge pump fuse located
next to the battery switch in the engine compartment. See chapter 3.
If the fuses “blow” or breakers “pop” due to an overload, the cause
should be investigated before replacing the fuse or resetting the
breaker. Only replace fuses with the same amperage and type. In
emergency situations, fuses installed in the fuse block for features
that are not used on your model can be used as replacements when
appropriately sized for the fuse your are replacing, but be careful of
electrical shock when removing or replacing a fuse.
FUNCTION AMPS TYPE PLACE
Accessory 1 (If Included) 15 Fuse Dash Fuse
Box
Accessory 2 (Not Available) 15 Fuse Dash Fuse
Box
Bilge Pump Manual 7.5 Fuse Dash Fuse
Box
Bilge Pump Automatic 10 Fuse Engine
Compartment
Blower 10 Fuse Dash Fuse
Box
Cabin Lights (Not Available) 5 Fuse Dash Fuse
Box
4-7
Systems
