7-20
CHAPTER 7
The bucket seat slider needs periodic inspection
and maintenance. Loosen the swivel knob located
on the slider and pull the slider off the pedestal.
Inspect all fasteners and metal for fatigue.
Lubricate the points shown in the illustration with
a marine type grease. type of grease will not run
off under warm temperatures. Use a paint brush
to apply the grease. Also, use silicone spray for
areas that can not be accessed with the grease. Reassemble slider to
pedestal with the delrin cup positioned correctly.
LUBRICATE ALL
SPLINES
LUBRICATE SLIDER PLATE
CHECK FASTENERS
FOR TIGHTNESS
HANDLE
HANDLEHANDLE
LUBRICATE
HANDLES &
BOLT
BOLT
BUCKET SEAT SLIDER MAINTENANCE
Seating
