Equipment Operation
6-21
Engine Hatch
The engine hatch is a mechanical
type with hydraulic assist rams. The
hydraulic rams aid in opening the
hatch as it is being lifted up.
To lift up the hatch access the latch
assembly located at the center bench
seat backrest. Insert your fi nger in
the notched upholstery area and
push up on the latch.
When closing the hatch make sure all
body parts are clear of the hatch itself before lowering it. LOCK the
latch by pushing down on the top of the upholstery until it latches.
NOTCH W/
LATCH
