HELM CONTROLS
It is important that the skipper fully understands all control equipment
located at the helm before operating the boat.
Each gauge is designed with a light bulb so it can be seen at night. On
most models, this is normally activated by the navigation lights. Dash
relay circuits are protected by fuses on the dash fuse panel located in
the starboard storage locker directly in front of the helm.
3-28
Chapter 3
2100 RX Typical Helm
Feature Switch Panel
Accessory Switch Panel
Ignition Switch Panel
Regal Vue Option
