Technical Information
12-13
CAPS/PLUGS
HALON EXTINGUISHER
BATTERY PARALLEL/
BLOWER&HATCH LIFT
TERMINAL STRIPS
BATTERY CHARGER/
ISOLATOR
FUEL LEVEL
SENDER/BOND
TRIM TABS/AFT BILGE PUMP/
TRANSOM BONDING BUSS
BATTERY SWITCH
PANEL
120VAC/12VDC
MAIN DISTRIBUTION PANELS
HEAD SYSTEM
ELECTRIC HATCH LIFT
FWD
STBD
NOTES:
1. HARNESS SHALL BE SECURED AT LEAST
EVERY 18 INCHES TO COMPLY WITH
ABYC/NMMA STANDARDS, OR AT LEAST
EVERY 12 INCHES TO COMPLY FOR
CE CERTIFICATION.
2. USE CHAFE PROTECTION AS NEEDED.
DATE:
DR. BY:
01-21-04
REV. DATE:
REGAL MARINE INDUSTRIES
ORLANDO FLORIDA 32809-7895
TELEPHONE (407) 851-4360
LATEST REV :
APP. BY:
VC SUMP TO DASH HARNESS INSTALL
DWG. NO.:
SCALE:
2300 JETPORT DRIVE
APP. BY:DR. BY:REVISION DESCRIPTION
EVC22B
DRAWING TITLE:
