L390E-2 / HZI390E-2 Direct Vent Gas Insert
INSTALLATION
5) Position Log 3 in front and to the right of Log 1. Log 3 fi ts in a recess in
the burner tray. Pull log forward on the burner tray until it rests against
the ridge in the burner tray shown below.
6) Position Log 4 in front and to the right of Log 3. Log 4 fi ts in a recess in
the burner tray. Pull log forward on the burner tray until it rests against
the ridge in the burner tray shown below.
7) When installed - ensure the air gap at the rear of the log is maintained -
as indicated by arrow below.
8) Identify the locators for Log 5 - a pin on Log 1 and a cavity in the front
right corner on the burner tray as shown below.
9) Orient Log 5 as shown below - then match up locators on log with those
in the fi rebox (indicated above).
10) Correct positioning of Log 5 is shown below.
Ridge in burner tray (highlighted)
Cavity in burner tray (highlighted)Pin on Log 1 (highlighted)
Log 5 - correct position L
Log 5 - correct position installed
Log 5 - correct position R
Ridge in burner tray (highlighted)
3
4
1
