L390E-2 / HZI390E-2 Direct Vent Gas Insert
49
PARTS LIST
MAIN ASSEMBLY
Part # Description
1 396-035 Door Frame
2 936-159 Window Gasket (sold per ft)
3 396-112 Window Gasket Retainer
4 396-045 Burner Mounting Bracket Right
5 396-111 Burner End Right
6 396-023 Control Cover
7 911-139 Pilot Assembly NG SIT
911-140 Pilot Assembly LP SIT
910-100 Pilot Orifi ce - NG
910-101 Pilot Orifi ce - LP
8 396-111 Burner End Right
9 396-010 Exhaust Baffl e
10 396-101 Light Cover
12 396-042/F Slide Tool
13 416-535 Flue Connector Plate Assy
14 396-018 Flue Connector Plate Gasket
15 393-030 Bulkhead Clamp
16 396-029 Bulkhead Clamp Gasket
17 904-658 Gas supply line (inlet)
18 904-165 Connector 3/8"MPT - 3/8"Flare
19 396-028 Valve Mounting Bracket - R
20 911-084 Valve NG 885
911-085 Valve LP 885
22 396-023 Control Cover
24 904-944 90° elbow 3/8"MPT-3/8"Flare
25 396-034 Valve mounting bracket - L
26 911-012 Ignition board SIT IPI
27 910-572 SIT Profl ame receiver
28 911-074 Pilot Assy Ground Wire
29 396-043 Firebox Liner Retainers
30 396-114 Burner End - L
Part # Description
31 904-943 Orifi ce mount
32 Air Shutter Assy
396-032 Air Shutter
396-033 Burner Mounting Bracket
396-116 Orifi ce Mounting Gasket
34 396-513 Bottom Door Latch Assy
35 904-946 NG orifi ce #37
904-947 LP orifi ce #53
36 396-125 Pilot Shield
37 396-046 Burner Mounting Bracket - L
38 396-113 Pilot Line Cover
39 904-691 Glass Clip Retainer (ea)
46 911-013 Profl ame Wire Harness w/ IPI/IPI Switch
47 911-080 Wire harness w/40" extension
* 397-969 LP Conversion Kit
* 396-930 Ceramic Log Kit (6 pc)
* 396-530 Ceramic Burner
* 396-901 Brick Panels - Brown
* 396-902 Brick Panels - Red
* 396-908 Enamel Panels
* 396-525 Glass Burner Assembly
* Various Glass Crystals
* 396-094 Glass Tray
* 396-091 Pilot Cover
* 396-122 Burner Screen
* 904-790 Magnets (ea)
919-234 Manual
* 911-071/P Fan Motor Only
* 911-149 Fan Thermodisc
* 911-030 Fan Control Module
* 910-590 Remote Control (Hand held) GTM
* 910-592 Remote Control (Hand held) GTMF
* 904-943 Gas supply line (outlet to burner orifce)
* 911-093 10 ft. extension cord (EB units)
* 911-137 Pilot Hood Holding Clip
* Part Not Shown
