38
L390E-2 / HZI390E-2 Direct Vent Gas Insert
INSTALLATION
OPTIONAL SCREEN INSTALLATION
1) Install the optional screen by hooking the top of the screen over the two
tab at the top of the glass door. Locations shown in the diagrams below.
2) Secure the screen by placing provided magnets between the back of the
screen and the unit in locations shown below.
3) To remove - reverse steps.
Tabs
