Regency
®
P33-10 Zero Clearance Direct Vent Gas Fireplace | 35
|
35
installation
Optional
WALL THERMOSTAT
A wall thermostat may be installed if desired, connect
the wires as per the wiring diagram. Use table below
to determine the maximum wire length.
Note: Preferable if the thermostat is installed
on an interior wall.
Regency
®
offers an optional programmable
thermostat but any 250-750 millivolt rated non-
anticipator type thermostat that is CSA, ULC or UL
approved may be used.
Thermostat Wire Table
Recommended Maximum Lead Length
(Two-Wire) When Using Wall
Thermostat (CP-2 System)
Wire Size Max. Length
14 GA. 50 Ft.
16 GA. 32 Ft.
18 GA. 20 Ft.
20 GA. 12 Ft.
22 GA. 9 Ft.
CAUTION
Do not wire millivolt
thermostat wires
to 120V wire.
1) Install the replacement battery into the
DC Sparker Box by opening the battery
compartment.
NOTE: The battery in the DC Sparker Box
will need to be replaced annually.
DC SPARKER BATTERY
REPLACEMENT
