10  Operating Instructions Temperature Control Unit 90smart/150smart
NOTE
Important - When switching between the operating modes Pressure and Leak
stop mode, the temperature control unit must be switched off at the I/O switch!
Displays
Display Remark
OUT 1
The heating is switched on when the LED is on
ALM
The cooler is switched on when the LED is on
Level
The light is on if there is insufficient heat carrier
Motor
The light is on if the thermal relay has been triggered
Setting the set-point value
 Press SET, Sv flashes
 Set the set-point value using the
or button
 Press SET, the new value is activated
Changing the parameter
 Press SET for a few seconds until Pv appears
 Pv value flashes
 Tap SET until Lkv appears
 Set Lkv to 1 (clearance)
 Tap SET until the desired parameter appears
 Set the value using the
or button
 Press SET for a few seconds - End (set-point value/actual value
is displayed)
Switch off
 Cool down device or temperature control circuit to a minimum of
80 °C
 Switch off the device/pump with the I/O switch
WARNING
Danger of injury from escaping hot cooling water!
Before detaching connecting lines from the temperature control circuit, first al-
low the temperature control unit to cool down, as a function of the outlet tem-
perature, and then switch it off!
Check that the pump is no longer running!
