REGLOPLAS 90smart - Technical Specifications; 90 smart;150 smart Data

V 11/2014
24  Maintenance Temperature Control Unit 90smart/150smart
Technical Data 90smart/150smart
Temperature Control Unit Type 90smart 150smart
Max. outlet temperature 90 °C 90 °C/150 °C
Heat carrier/medium Water Oil
Filling capacity 7.0 l 7.5 l
Max. expansion volume 2.5 l 4.5 l
Heating capacity 6/9 kW 6 kW
Heating switch SSR relay SSR relay
Cooling capacity
51 kW (1K)
75 kW (2K)
29 kW
at outlet temperature 80 °C 140 °C
at cooling water temperature 20 °C 20 °C
Pump type TP20 TS22 TP20 TS22
Motor power (pump) 0.5 kW 1.1 kW 0.5 kW 1.1 kW
Max. delivery rate 60 l/min 70 l/min 60 l/min 70 l/min
Max. delivery pressure 3.8 bar 5.4 bar 3.8 bar 5.4 bar
Control System RT34 / RT70 Control System
Measurement type (standard) Pt100
Control voltage 115/230 V, 50/60 Hz
Input supply voltages
200-600 V
50/60 Hz
Total power (see specification plate) (see specification plate)
Outlet/inlet connections (standard) G 1/2" G 1/2"
Cooling water supply connections
(standard)
G 1/2" G 1/2"
Degree of protection IP40 IP40
Dimensions W/H/D 202/560/661 mm 202/560/661 mm
Weight approx. 44 kg approx. 50 kg
Colour RAL 9006/7016 RAL 9006/7016
Ambient temperature max. 40°C max. 40°C
Continuous sound pressure level < 70 dB(A) < 70 dB(A)
