REGLOPLAS 90smart - Performance Graphs; Pump Capacity Graph

V 11/2014
Temperature Control Unit 90smart/150smart Maintenance  27
Graph (pump capacity)
1 - Pump curve TP20
2 - Pump curve TS22, TS22H
Pump capacity - Delivery rate V as a
function of pressure (p), bypass not tak-
en into account
