REGLOPLAS 90smart - Components and Spare Parts; 150 smart Components and Parts

V 11/2014
Temperature Control Unit 90smart/150smart Maintenance  31
Item Designation Item Designation
9 Castor with wheel lock B1 Temperature probe - internal
30 Power cable E21 Heating
35 Pump F5 Safety thermostat
38 Tank with insulation M10 Pump motor
41 Cooler P1 Control system
46 Float Q1 Main switch
54 Filler cap S3 Level switch (see corresponding chapter)
56h Check valve Bypass T5 Control transformer
58 Bypass V21 SSR relay with heat sink
60 Filter - cooling water V21a Seal for SSR relay
63 System water IN Y2 Solenoid valve (auto. water refill)
66 Cooling water IN Y6 Solenoid valve (cooling)
67 Cooling water OUT Y13 Solenoid valve (suction)
68 Discharge port
69 Filler pipe
69a Filler pipe (option)
70 Overflow
72 Outlet
73 Inlet
75 Castor
NOTE
See electrical wiring diagram of the temperature control unit for additional elec-
trical components!
CAUTION
Only authentic (OEM) Regloplas spare parts may be used!
In case of damage from the use of non-OEM parts, the warranty will be rendered
null and void!
