V 11/2014
34 Maintenance Temperature Control Unit 90smart/150smart
Item Designation Item Designation
9 Castor with wheel lock B1 Temperature probe - internal
30 Power cable E21 Heating
35 Pump F5 Safety thermostat
38 Tank with insulation M10 Pump motor
41 Cooler P1 Control system
46 Float Q1 Main switch
54 Filler cap S3 Level switch (see corresponding chapter)
60 Filter - cooling water T5 Control transformer
66 Cooling water IN V21 SSR relay with heat sink
67 Cooling water OUT V21a Seal for SSR relay
68 Discharge port Y2 Solenoid valve (auto. water refill) (option)
69 Filler pipe Y6 Solenoid valve (cooling)
70 Overflow Y13 Solenoid valve (suction)
72 Outlet
73 Inlet
75 Castor
NOTE
See electrical wiring diagram of the temperature control unit for additional elec-
trical components!
CAUTION
Only authentic (OEM) Regloplas spare parts may be used!
In case of damage from the use of non-OEM parts, the warranty will be rendered
null and void!
