MACH-Air™ VAV Controller
Physical Dimensions
 2002 Reliable Controls™ Corporation
Physical Dimensions
35.8
[1.41]
35.8
[1.41]
36.6
[1.44]
112.8
[4.44]
205.5
[8.09]
58.4
[2.30]
49.5
[1.95]
241.3
[9.50]
53.9
[2.12]
22.4
[0.88]
62.5
[2.46]
19.0
[0.75]
19.0
[0.75]
133.0
[4.84]
179.3
[7.06]
OPTIONAL
CONNECTOR
COVER
TOP VIEW
This controller is intended to be
installed in accordance with the
National Electric Code or the
Canadian Electric Code, Part 1,
and in a manner acceptable to the
local authority having jurisdiction.
