MACH-Air™ VAV Controller
 2002 Reliable Controls™ Corporation
Getting Started
Getting Started
This guide identifies the physical installation procedure and
connection of the MACH-Air™ VAV controller within a Reliable
Controls™ MACH-System.
There are many important concepts and practices that
accompany the use of the MACH-Air™
controller. This
document is intended to provide installation and setup
procedures for first time users. The most important concepts
that are crucial to the reliable operation of the MACH-Air™ are
introduced.
Product Overview
The MACH-Air™ VAV controller features:
! Three user configurable universal inputs.
! Three user configurable universal outputs.
! Onboard velocity sensor.
! Relocatable damper actuator.
! SMART-Net™ port.
! EIA-485 network port.
The MACH-Air-T™ VAV controller outputs:
! One single stage triac (24 VAC, 1A binary output).
! One dual stage triac (24 VAC, 1A binary output).
! One user configurable universal output.

Reliable Controls MACH-Air Specifications

General

Brand	Reliable Controls
Model	MACH-Air
Category	Controller
Language	English
