Reliable Controls MACH-Air User Manual

29
MACH-Air™ VAV Controller
SMART-Sensor
™
Connection
 2002 Reliable Controls™ Corporation
SMART-Sensor
™
Connection
The MACH-Air™ VAV controller supports up to four
SMART-Sensors™ (Part# - SS). The SMART-Sensors™ are
ideal for measuring space/zone temperatures and providing
user level adjustments to temperature set points.
See the SMART-Sensor™ Quick Start Guide for installation
details.
Ensure that the SMART-Sensor™
voice cable is connected to the
Smart-Net™ port.
SMART-Sensors™ need to be
properly addressed using the
configurable internal jumpers.
