REMKO ML 263 DC - Page 42

Outdoor unit ML 523 DC AT
X
CN302
CN303
CN8
CN10
CN11
CN301
CN13
CN12
CN15
3
4
CN401
CN400
CN9
CN104
CN103
CN102
CN100
CE-KFR26W/BP3(PFC).D.13.WP2-1 202302130906
CN5
CN6
5
8
4
7
B CA
2
3
1
6
Fig. 50: Electrical drawings
A: Connection to terminal block, power supply and
supply to the indoor unit (contact L (1))
B: Connection to terminal block, power supply and
supply to the indoor unit (contact N und 2(N))
C: Connection to terminal block, power supply and
supply to the indoor unit (contact S)
1: Heater 2 (optional)
2: Heater 1 (optional)
3: 4-way valve
4: Condenser fan
5: Probe heat gas
6: Probe outside air, probe condenser
7: Inductor
8: Compressor
REMKO ML...DC
42
