REMKO ML 263 DC User Manual

2 Technical data
2.1 Unit data
Series ML 263 DC ML 353 DC ML 523 DC
Operating mode
Inverter wall-mounted room air conditioner combination
for cooling and heating
Nominal cooling output
1)
kW
2.80 (1.00-3.70) 3.50 (1.10-4.10) 5.10 (3.10-6.20)
Energy efficiency ratio SEER
1)
5.7 5.8 6.5
El. rated power consumpt., cooling
1)
kW
0.90 1.05 2.19
El. rated current consumpt., cooling
1)
A
3.90 4.50 9.50
Power consumption, annual, Q
CE
3)
kWh 172 187 269
Energy efficiency ratio, cooling
1)
A+ A+ A++
Nominal heat capacity
2)
kW
2.60 (0.90-3.80) 3.70 (1.00-4.40) 5.30 (1.50-6.40)
Energy efficiency ratio SCOP
4)
3.8 3.8 3.8
El. rated power consumpt., heating
2)
kW
0.72 0.91 1.89
El. rated current consumpt., heating
2)
A
3.10 3.90 8.20
Power consumption, annual, Q
HE
3)
kWh 958 1179 1805
Energy efficiency ratio, heating
2)
A A A
Max. power consumption kW 2.00 2.30 2.55
Max. current consumption A 9.00 10.50 11.50
EDP no. 1633263 1633353 1633523
Data specific to indoor unit ML 263 DC IT ML 353 DC IT ML 523 DC IT
From serial number: 1305... 1307... 1309...
Application area (room vol.), approx.
m
3
80 110 160
Adjustment range, room temperature °C +17 to +30 +8 with "FP" function
Operating range °C +17 to +32
Air flow volume per level m³/h 400/530/620 410/570/640 440/500/680
Sound pressure level p. speed set.
5)
dB (A) 29/37/41 29/39/42 28/31/33
Sound pres. level, Silent/Turbo mode
5)
dB (A) 26/43 22/44 26/41
Sound power level max. dB(A) 58 58 55
Enclosure class IP X 0
Condensate drainage connection mm 18
Dimensions: H/W/D mm 275/800/188 275/800/188 275/940/205
Weight kg 6.5 8.0 9.0
EDP no. 1633264 1633354 1633524
REMKO ML...DC
8

REMKO ML 263 DC Specifications

General

Brand	REMKO
Model	ML 263 DC
Category	Air Conditioner
Language	English
