REMKO ML 263 DC - Page 52

Resistance values for probes T1, T2, T3 and T4
Temperature
(°C)
5 10 15 20 25 30 40 50 60
Resistance value
(kW)
26.9 20.7 16.1 12.6 10.0 8.0 5.2 3.5 2.4
Resistance values for probe T5
Temperature
(°C)
5 15 25 35 60 70 80 90 100
Resistance value
(kW)
141.6 88 56.1 36.6 13.8 9.7 6.9 5.0 3.7
Progression - temperature / resistance
W
T
T5
T1, T2, T3, T4
Fig. 51: Progression - temperature / resistance
W: Resistance (kW) T: Temperature (°C)
REMKO ML...DC
52
