ENGINE AND PERIPHERALS
Tightening torques (in daNm)
10
* Spark plug M12 tighten to 2 daNm
Spark plug M10 tighten to 1.6 daNm
** 1
st
model:
– coolant pipe : 0.8 to 1 daNm
– coolant rail : 2 to 2.5 daNm
2
nd
model:
– cooling jets only : 1.2 to 1.4 daNm
*** Seethe cylinder head tightening procedure page 10-16
10-12
A 7
B 2.3
C 6.5±0.25
D 8.75 to 9.75
E 1.3
F 4 to 4.5
