AUTOMATIC TRANSMISSION
Converter seal
23
ESSENTIAL SPECIAL TOOLS
B. Vi. 1457 Tool for fitting the converter seal
Mot. 587 Tool for extracting the seal
The converter seal can only be removed following
removal of the automatic transmission and the
converter (refer to the relevant section).
REMOVAL
Remove the converter as far as possible in the cen-
treline.
Warning: the converter contains a significant
quantity of oil which may flow out on removal.
Using tool Mot. 587, remove the seal taking care
not to damage the surfaces with which it is in
contact.
REFITTING
The operation must be carried out with great
care. Coat all the surfaces in contact with oil.
Fit the new seal (coated with oil) fully using tool B.
Vi. 1457.
Check that the converter is fitted correctly.
23-15
