ENGINE AND PERIPHERALS ASSEMBLY
Specifications
10
15156R
Details of mark (A) :
- mark (B) is only used by the supplier,
- mark (C) identifies the camshafts:
A = Inlet
E = Exhaust
- mark (D) indicates the engine type
Example:
F4RE668 104 14 22
BCD
VALVES
Valve lift (in mm)
Inlet: 10
Exhaust: 10
Camshafts
The camshafts are identified
- either by a mark (A).
- or by the ends of the camshafts.
15152R
- F exhaust camshaft
- G inlet camshaft
10-3
