Renault KlGER - Page 110

3.4
AIR VENTS, air outlets
(2/2)
Air flow
Lateral Air vents(Left and Right)
– To move the front vanes up/down,
move the centre knob 9 upwards/down-
wards;
– To open/close the side vanes (inside
the centre knob), move the centre knob
9 towards outside/innerside respec-
tively;
Air vents are having rear fixation.To
service air vents, complete Instrument
panel assembly had to be disassem-
bled.
Centre Air Vents
(depends on the vehicle)
– To move the front vanes up/down,
move the centre knob 10 upwards/
downwards;
– To open/close the centre vanes
(inside the centre knob), move the
centre knob 10 towards outside/inner-
side respectively;
Air vents are having rear fixation.To
service air vents, complete Instrument
panel assembly had to be disassem-
bled.
9
10
Rear console Air Vents
(depends on the vehicle)
– To move the front vanes up/down,
move the centre knob 11 upwards/
downwards;
– To open/close the centre vanes
(inside the centre knob), move the
centre knob 11 towards outside/inner-
side respectively;
Air vents are having rear fixation.To
service air vents, complete console as-
sembly had to be disassembled.
11
