3.21
BOOT
To open
From the outside
Depending on the vehicle, press un-
locking button in the Radio frequency
remote control key (or) press Unlocking/
locking the tailgate button in handsfree
card and lift the tail gate.
(Refer to the instructions in chapter1)
Opening the tail gate manually f rom
the inside
If it is impossible to unlock the tailgate
from outside, it can be done manually
from inside;
- access the luggage compartment by
tilting the rear bench seatback(s);
- insert a pencil or similar object in
recess 1 and slide the unit as shown in
the illustration;
- push the tail gate to open it.
The attaching of any
carrying device (bike rack,
luggage box etc) resting on
the luggage compartment
lid is prohibited. To install a carrying
device on your vehicle, contact an
authorised dealer.
1
To open
From inside
Depending on the vehicle, press 2 to
lock (or) unlock the tail gate.
2
