3.22
REAR PARCEL SHELF
Rear Parcel shelf 2
(depending on the vehicle)
– Unhook the two straps 1 of the trunk
door;
– Lift the parcel shelf 2 to certain height
in the direction A;
– Incline the parcel shelf 2 along the di-
rection B to certain angle and pull to
remove the parcel shelf out from the
vehicle.
To refit, proceed in the reverse order.
Do not place any objects,
especially heavy or hard
objects, on the parcel shelf.
These may pose a risk to
the vehicle occupants if the driver
has to brake suddenly or if the ve-
hicle is involved in an accident.
1 2
A
B
