1.36
CHILD SEATS: ATTACHMENT BY THE SEAT BELT (2/2)
Seating Position
Mass Group
Weight of
the child
Front passenger seat
Second row seats
LEFT RIGHT CENTRE
Group 0 Upto 10 kg X U U X
Group 0+ Upto 13 kg X U U X
Group I 9 to 18 kg X U U X
Group II 15 kg to 25 kg X U U X
Group III 22 kg to 36 kg X U U X
The table below summarises the information already shown in the diagram on the previous pages, to ensure the applicable regu-
lations are respected.
X = Seat not suitable for fitting child seats.
U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
