5.11
REAR LIGHTS: replacing bulbs
Indicators/Brake and side lights
In the luggage compartment,
remove the access grille by raising
tab 1.
The bulbs are under
pressure and can break
when replaced.
Risk of injury.
Raise tabs 2 and 3 to unclip lamp
holder 4.
5 Side and brake lights
Two filament bayonet bulb:
P21/5 W.
6 Direction indicator light
Orange PY21 W bayonet bulb.
