5.12
REAR LIGHTS: replacing bulbs (continued)
Rear fog lights / Reversing and
side lights
On the tailgate, unclip the cover 6
from the light unit concerned to
access the retaining bolt.
Unscrew it.
The bulbs are under
pressure and can break
when replaced.
Risk of injury.
From outside, remove the rear lights
unit.
Unclip bulb holder 7 to access the
bulbs.
8 Side light
Two filament bayonet bulb:
P21/5 W.
9 Fog light
Pear-shaped bulb, bayonet type
P21 W.
10 Reversing light
Pear-shaped bulb, bayonet type
P21 W.
