Renesas E2 Emulator User Manual

E2/E2 Lite Overview
R20UT4582EJ0100 Rev.1.00 Page 7 of 30
Jul.16.19
1.3 Supported Devices
Table 1.1 Supported Device List
Supported Device
E2
E2 Lite
SWD I/F
FINE I/F
SCI I/F
SWD I/F
JTAG I/F
SCI I/F
RE0 series DBG  PRG DBG  
*
DBG: Can be used for debugging, PRG: Can be used for flash programming
1.4 Debugging Functions
Table 1.2 Debugging Function List
Item
Supported
Description
Memory reference or change during
program execution
√ 
Break
Software break √ 2000 points
Hardware break √
Execution address: four points; data access: two
points
Forced break
√

Trace √
Information acquired:
• Branch-source PC values, branch-destination
PC values, occurrence of interrupts, and return
from interrupts
Start event:
• Start of user-program execution
End events:
• Stopping the user program and trace memory
becoming full
Performance measurement √
Measurement item:
Between start and stop of user program execution
Hot plug-in
× 
Extended
function of the
E2
Solution for the tuning
of current
consumption
×
Current consumption by the user system is
measured when the power is supplied from the E2.
External trigger
input/output
×
External triggers can be input to or output from the
E2 expansion interface.
√: Supported; ×: Not supported
