CHAPTER 3 SOFTWARE CONFIGURATION
Application Note U17209EJ1V0AN
32
3.2 Peripheral I/O
The following types of peripheral I/O functions are used in this reference system.
Table 3-1. List of Peripheral I/O Functions
Function
Peripheral I/O
Function Name
(V850E/IA1)
Peripheral I/O
Function Name
(V850E/IA2)
Peripheral I/O
Function Name
(V850E/IA3)
Peripheral I/O
Function Name
(V850E/IA4)
Peripheral I/O
Function Name
(V850E/MA3)
Inverter timer Timer 00 (TM00) Timer 00 (TM00) Timer Q0 (TMQ0) Timer Q0 (TMQ0) Timer Q0 (TMQ0)
10 ms timer Timer 21 (TM21) Timer 21 (TM21) Timer P0 (TMP0) Timer P0 (TMP0) Timer D0 (TMD0)
Motor control timer Timer 3 (TM3) Timer 3 (TM3) Timer P1 (TMP1) Timer P1 (TMP1) Timer D1 (TMD1)
Speed measuring timer Timer 4 (TM4) Timer 4 (TM4) Timer P2 (TMP2) Timer P2 (TMP2)
Timer ENC10
(TMENC10)
U-phase current ANI00 ANI00 ANI00 ANI00 ANI0
V-phase current ANI10 ANI10 ANI10 ANI10 ANI1
Setting speed (volume) ANI01 ANI01 ANI01 ANI01 ANI4
U-phase zero-cross input INTP20 INTP20 INTP2 INTP2 INTP130
V-phase zero-cross input INTP21 INTP21 INTP3 INTP3 INTP131
W-phase zero-cross input INTP22 INTP22 INTP4 INTP4 INTP132
CW key input P40 P40 P40 P40 P40
CCW key input P41 P41 P41 P41 P41
STOP key input P42 P42 P42 P42 P42
WDT reset output P43 P30 P30 P30 P43
LED output
PDL0 to PDL11,
PDL15
PDL0 to PDL11,
PDL15
PDL0 to PDL11,
PDL15
PDL0 to PDL11,
PDL15
PDL0 to PDL11,
PDL15
