Application Note U17209EJ1V0AN
7
For details of hardware functions (especially register functions, setting methods, etc.)
and electrical specifications
→ See the V850E/IA1 Hardware User’s Manual, V850E/IA2 Hardware User’s
Manual, V850E/IA3, V850E/IA4 Hardware User’s Manual, and V850E/MA3
Hardware User’s Manual.
For details of instruction functions
→ See the V850E1 Architecture User’s Manual.
Conventions Data significance: Higher digits on the left and lower digits on the right
Active low representation: xxx (overscore over pin or signal name)
Memory map address: Higher addresses on the top and lower addresses on
the bottom
Note: Footnote for item marked with Note in the text
Caution: Information requiring particular attention
Remark: Supplementary information
Numeric representation: Binary ... xxxx or xxxxB
Decimal ... xxxx
Hexadecimal ... xxxxH
Prefix indicating the power
of 2 (address space,
memory capacity): K (kilo): 2
10
= 1,024
M (mega): 2
20
= 1,024
2
G (giga): 2
30
= 1,024
3
Data type: Word: 32 bits
Halfword: 16 bits
Byte: 8 bits
Related documents The related documents indicated in this publication may include preliminary versions.
However, preliminary versions are not marked as such.
Documents related to V850E/IA1, V850E/IA2, V850E/IA3, V850E/IA4, V850E/MA3
Document Name Document No.
V850E1 Architecture User’s Manual U14559E
V850E/IA1 Hardware User’s Manual U14492E
V850E/IA2 Hardware User’s Manual U15195E
V850E/IA3, V850E/IA4 Hardware User’s Manual U16543E
V850E/MA3 Hardware User’s Manual U16397E
V850E/IA1, V850E/IA2 AC Motor Inverter Control Using Vector
Operation Application Note
U14868E
Inverter Control by V850 Series 120° Excitation Method Control by Zero-
Cross Detection Application Note
This manual
