D.2 Connecting a Dust-
Generating Device
The unit is equipped with a power outlet on the back,
designed for a two-contact plug with a ground contact
(either in accordance with DIN 49441 or NEMA), to
which dust-generating equipment can be connected
(Figure 4a).
A corresponding connector (Figure 31) is included
in the standard delivery of 230 V units with outlets in
accordance with DIN 49441. This connector can be
used to make an adapter for your local plug congu-
ration.
This adapter may only be made by a
The adapter must not interrupt the ground
circuit system!
E. Repairs
Repairs may only be performed by qualied electri-
cians or authorized dealers.
Depending on the material trapped by the lters, pro-
tective gear may need to be worn during repairs.
F. Disposal Information
F.1 Disposing of Consumables
Full dust bags and lters – including motor and elec-
tronics lters – must be disposed of under compli-
ance with locally applicable regulations.
Depending on the material trapped by the lters, pro-
tective gear may need to be worn during disposal.
F.2 Disposing of the Unit
The unit must be disposed of by an authorized recy-
cling operation. The selected rm must be informed
of all possibly health-hazardous residues in the unit.
F.3 Disposal instructions for
countries in the EU
To conserve and protect the environment, prevent
environmental pollution and improve the recycling of
raw materials, the European Commission adopted
a directive that requires the manufacturer to accept
the return of electrical and electronic units for proper
disposal or recycling.
Within the European Union units with this symbol
should not therefore be disposed of in unsorted do-
mestic waste:
Information about correct disposal and return options
is available on the Internet at:
www.renfert.com
F.4 Information specically for
customers in Germany
Renfert electrical units are intended for commercial
use.
These units should be returned directly to Renfert
and not taken to communal collection sites for electri-
cal units.
Information about current return options is available
on the Internet at
www.renfert.com
Mains voltage: 230 V, 50 Hz
120 V, 60 Hz
100 V, 50/60 Hz
Dust extractor power consumption: 1300 W (230 V)
1200 W (100 V / 120 V)
Unit power outlet maximum
connecting value: 2300 W (230 V)
600 W (100 V / 120 V)
Total connected power: 3600 W (230 V)
1800 W (100 V / 120 V)
Mains input fuse (Figure 4b): 2x 5 A (T) (230 V)
2x 12A (T) (100 V / 120 V)
Sound pressure level in accord. with
DIN 45635 at maximum airow: 56 dB(A)
Airow, max: 3300 l/min
Vacuum pressure, max: 20 kPa [2.9 psi]
Filter surface area, ne particle lter: approx. 0.8 m²
Fill volume, dust bag: approx. 7.5 l
Power cord length: approx. 2 m [78.74 inches]
Dimensions
(height x width x depth): 595 x 225 x 565 mm
[23.4 x 8.8 x 22.2 inches]
Weight (empty): approx. 21 kg
Ø suction ttings:
Internal: 32.5 mm [1.28 inches]
External: 40 mm [1.57 inches]
