17
Preparation
3. If you need to extend the
auxiliary 12V power cable,
cut it at any part of the
auxiliary 12V power cable
and strip off some of the
insulation.
NOT
z
When extending the 12V power cable, confirm the polarity of the cable before connecting it
to the auxiliary one. A reverse polarity contact will result in abnormal operations. The length
of the extension cable should not exceed 10 meters (32.8 feet).
4. Strip part of the insulation
off the extension cable
and connect it to the cut-
off point of the auxiliary
12V power supply cable
and wrap the cut-off areas
with the insulation tape.
5. Use the skill saw to cut the installation hole according to the
gray mark on the mounting template.
Required Tools Inspection Mounting Location
To Next Page
