Renogy REGO User Manual

14
:LULQJ'LDJUDP
:LULQJ'LDJUDP
WARNING
please read the instructions carefully
Before working on this product.
CHARGER INPUT
PROTECT
INVERTER OUTPUT
PROTECT
BTS
NO
NC
DRY
OUTPUT
INPUT
N
N
L
L
CONTACT
REMOTE
C
CAN
High voltage,in order to avoid risks,
AC/INV
OFF
ON
CHC
FAULT
Pure Sine Wave Inverter Charger
GITIVE
ATIVE
Remote control
Temperature sensor
Ground
Negative (DC)
Positive (DC)
Shore Power or Generator
(120V Single Phase, 40A Max.)
AC Load Center
AC Loads
(120V Single Phase, 30A Max.)
Battery System (12V)
DC Fuse
(400A)
Chassis Ground Lug
+
Wired Remote Control
ON ERR
RMS-P2
Neutral wire (AC)
Live wire (AC)
NOT
E
z
'RQRWXVHWKHWHPSHUDWXUHVHQVRURQD/L)H32/)3EDWWHU\ZKLFKFRPHVZLWKD%DWWHU\
0DQDJHPHQW6\VWHP%06

Renogy REGO Specifications

General

Output Voltage	12V/24V
Output Current	20A
Charging Algorithm	Multi-stage (Bulk, Absorption, Float)
Battery Compatibility	Flooded, Lithium
Operating Temperature	-20°C to 50°C
Protection	Over-voltage, Short-circuit, Reverse polarity
Communication	Bluetooth
Cooling Method	Fan
