REPLIGEN OPUS 14 - Product Contact Materials; Table 3. Physical Specifications Summary (OPUS 5 - 30 Columns)

UG-OPUS® 5-80R
8
OPUS® 5-80R Pre-packed Chromatography Columns
Column Diameter
Outer Diameter
(including caps)
7 cm 10 cm 16 cm 20 cm 21 cm 27 cm 33 cm 38 cm
Inlet/Outlet
Flow Path
Internal
Diameter
3.45 mm
5/32
inch
4.57 mm
3/16
inch
6.35 mm
1/4 inch
6.35 mm
1/4 inch
6.35 mm
1/4 inch
6.35 mm
1/4 inch
9.53 mm
3/8 inch
9.53 mm
3/8 inch
Inlet and Outlet
Port Connectors
3/4 inch
mini
Tri-
Clamp
3/4 inch
mini
Tri-
Clamp
3/4 inch
mini
Tri-
Clamp
3/4 inch
mini
Tri-
Clamp
3/4 inch
mini
Tri-
Clamp
3/4 inch
mini
Tri-
Clamp
3/4 inch
mini
Tri-
Clamp
3/4 inch
mini
Tri-
Clamp
Table 3. Physical Specifications Summary (OPUS
®
5 – 30 Columns)
Column Diameter
Physical Attributes 45.7 cm 59.9 cm 79.9 cm
Internal Cross Section 1,640 cm
2
2,818 cm
2
5,014 cm
2
Column Body
Pressure Rating
3 Bar 3 Bar 3 Bar
Bed Height Range* 5 – 30 cm 5 – 30 cm 10 – 30 cm
Column Volumes
10 cm Bed Height
20 cm Bed Height
30 cm Bed Height
16 L
33 L
49 L
28 L
56 L
84 L
50 L
100 L
150 L
Assembled Column Height
(cm)^
≤ 22 cm BH: ~90 cm
>22 cm BH: ~116 cm
≤ 22 cm BH: ~93 cm
>22 cm BH: ~120 cm
≤ 20 cm BH: ~97 cm
>20 cm BH: ~123 cm
Outer Diameter (including
caps)
54 cm 68 cm 91 cm
Inlet/Outlet Flow Path
Internal Diameter
12.7 mm
1/2 inch
19.1 mm
3/4 inch
19.1 mm
3/4 inch
Inlet and Outlet Port
Connectors
Per ASME BPE Standards,
Current Edition
3/4 inch
mini Tri-Clamp
1 inch
Tri-Clamp
1 inch
Tri-Clamp
*Resin Recovery design columns have a minimum bed height of 10 cm.
^These values are estimates based on the target bed height (BH) of the column.
2.6 Product Contact Materials
OPUS® 5 – 80R Columns are designed using polymers which are best suited to downstream
processing applications (Table 4).
