en
27
Installation
CommissioningSettingsTroubleshooting
Accessories
Display
Min. speed R1 / R2 / PWM
Adjustment range: 20 ... 100 %
Factory setting: 100 % (PWM = 30 %)
Max. speed R1 / R2 / PWM
Adjustment range: 20 ... 100 %
Factory setting: 100 %
The adjustment channels Min. speed and Max. speed are used for limiting the
minimum and the maximum speed of the circulating pump to the target temperature.
General
In the General menu the menu language, temperature unit, time and date can be
adjusted. Normally, these settings have been made during commissioning. They can
be subsequently changed in this menu.
Language
Language selection
Selection: Deutsch, English, Français, Italiano, Español
Factory setting: German
Unit
Temperature unit
Selection: °C, °F
Factory setting: °C
Time
Adjustment range: 00:00 ... 23:59
Date
Adjustment range: 01.01.2001... 31.12.2099
In the General menu, the version number and the software number are additionally
displayed.
