Page #31 background imageLoading...
Page #31 background image
en
31
Installation
CommissioningSettingsTroubleshooting
Accessories
Display
Display Description Adjustment range
Factory setting
Profile PWM speed control signal profile Solar, Heating Solar
Min speed PWM Minimum speed PWM 20 ... 100 % 30 %
Max. speed PWM Minimum speed PWM 20 ... 100 % 100 %
Signal type R1 Speed control signal relay 1 Std., PWM Std.
Profile PWM speed control signal profile relay 1 Solar, Heating Solar
Min speed R1 Minimum speed relay 1 20 ... 100 % 100 % (PWM=30 %)
Max. speed R1 Maximum speed relay 1 20 ... 100 % 100 %
Signal type R2 Speed control signal relay 2 Std., PWM Std.
Profile PWM speed control signal profile relay 2 Solar, Heating Solar
Min speed R2 Minimum speed relay 2 20 ... 100 % 100 % (PWM=30 %)
Max. speed R2 Maximum speed relay 2 20 ... 100 % 100 %
General:
Language Language selection Deutsch, English, Français, Italiano, Español Deutsch
Unit Selection temperature unit °C, °F °C
Time Time
Date Date
Version Version number
Software Software version
Installer:
Tset SFB / boiler Set temperature difference SFB / boiler 0.5 ... 50.0 K 10.0 K
Rise Rise speed control relay 1 0.0 ... 50.0 K 1.0 K
Rise 2 Rise speed control relay 2 0.0 ... 50.0 K 1.0 K
Tmin SFB / boiler
Hysteresis SFB / boiler minimum limitation 3.0 ... 15.0 K 5.0 K
Tmax store Hysteresis maximum store temperature 1.0 ... 25.0 K 2.0 K
Tmax SFB / boiler Hysteresis SFB / boiler maximum limitation 1.0 ... 25.0 K 5.0 K
Interval Interval mixer control 1 ... 20 s 4 s
Frost protection Antifreeze function Yes, No No
TAntifreeze Antifreeze temperature -40 ... +10 °C +5 °C
Blocking protection Blocking protection function Yes, No No
Start BP Blocking protection starting time 00:00 ... 23:59 19:00
Installer Installer option Yes, No No
Reset Reset to factory settings Yes, No No
User code:
Code User code 0000 ... 9999 0000
